Price:
3,675.00 ৳
Specification
| MAIN FEATURES | |
| Chipset | Intel® H81 |
| GENEREL INFORMATION | |
| Audio Chipset | Realtek Chip, ALC 6-channel audio |
| Back Panel I/O Ports | 1 x VGA Port 1 x HD Port 1 x LAN (RJ45) Port 2 x USB 3.0 Ports(Blue) 4 x USB 2.0 Ports 3 x flexible audio jacks |
| CPU Socket | Intel Socket 1150(4th Gen Core i7/ i5/i3 Processors) |
| Graphic | Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI / VGA ports |
| INTERNAL I/O | 1 x USB 3.0 connector（19pin)， supports 2*USB 3.0 ports 1 x USB 2.0 connector， supports 2*USB 2.0 ports 4 x SATA 6Gb/s Ports 1 x 4 -pin CPU_FAN/SYS_FAN connectors 1 x 24-pin ATX power connector 1 x 4-pin 12V ATX Power connectors 1 x DEBUG connector 1 x F_Audio connector 1 x Internal Speaker connector 1 x F_Panel connector |
| LAN | Realtek Chip, 1 x 100M（Optional 1000M） |
| Memory Support | 2 * DDR3 1066/1333MHz DIMM |
| Memory Type | DDR3 |
| Processor | Support Intel® Socket 1150 for 4th Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® Turbo Boost Technology 2.0 |
| Slots | 1 x PCIe x16 3.0/2.0 slot 1 x PCIe x1 2.0 slot |
| Storage | 1 x M.2 Socket, Supports 2242 SSD 4 x SATA 6Gb/s Ports |
| USB | USB 3.0 |
| WARRANTY INFORMATION | |
| Warrantty | 1 Year |
Esonic Intel H81DA1 DDR3 Motherboard
Esonic Intel H81DA1 DDR3 Motherboard is a reliable and cost-effective motherboard designed to support Intel® Socket 1150 processors, making it an excellent choice for users seeking a dependable platform for their computing needs. Whether you're building a home office PC or a budget-friendly gaming rig, this motherboard has the features and performance to meet your requirements. One of the standout features of the H81DA1 motherboard is its broad processor compatibility. It supports a wide range of Intel processors, including 4th Generation Core™ i7, Core™ i5, Core™ i3, Pentium®, and Celeron® processors. This flexibility allows users to choose the CPU that best suits their needs, from power-hungry tasks to everyday computing. The Intel® H81 chipset ensures stable and efficient performance, making it suitable for various computing tasks. It comes with two DDR3 DIMM slots, supporting memory speeds of 1066/1333MHz, allowing you to install up to 16GB of RAM for smooth multitasking and application handling. For graphics, the motherboard features an integrated Intel® HD Graphics processor with support for multiple display outputs, including HDMI and VGA ports. This enables users to connect multiple monitors or displays for enhanced productivity or gaming experiences. In terms of expansion slots, the motherboard offers a PCIe x16 3.0/2.0 slot for installing a dedicated graphics card, as well as a PCIe x1 2.0 slot for additional expansion cards. It also includes an M.2 socket for SSD storage and four SATA 6Gb/s ports for connecting traditional hard drives and SSDs. Networking is handled by a Realtek LAN chip, providing a reliable and fast Ethernet connection, and the Realtek ALC 6-channel audio chip delivers clear and immersive audio for your multimedia needs. The motherboard offers a convenient array of USB ports, including four USB 3.0 ports on the back panel and two on the mid-board, along with six USB 2.0 ports (four on the back panel and two on the mid-board), ensuring you have plenty of connectivity options for peripherals and devices. The Esonic Intel H81DA1 motherboard also features a compact and space-saving micro ATX form factor with dimensions of 215 x 170mm, making it suitable for various PC case sizes With a 1-year warranty, the Esonic Intel H81DA1 DDR3 Motherboard provides users with peace of mind, knowing that their investment is protected. Overall, this motherboard offers a balance of performance, compatibility, and affordability, making it an excellent choice for budget-conscious builders and users seeking a dependable foundation for their computing needs.
