Key Features
Model: KVR32S22S8/16
Memory Capacity: 16GB
Form Factor: DDR4
Speed (Data Rate): 3200MT/s
CAS Latency: CL22, Pin: 260 Pin
Key Features | |
Type | DDR4 |
Capacity | 16GB |
Frequency | 3200Mhz |
Operating voltage | 0 Degree C to + 85 Degree C |
Latency | CL22 |
Physical dimension | |
Heat Sink Color | No |
Pin | 260-pin DIMM |
Warranty Information | |
Warranty | Life Time Warranty |
The Kingston Value RAM 16GB DDR4 3200MHz Laptop RAM is a 2G x 64-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8, non-ECC memory module built with eight 2G x 8-bit FBGA components. The SPD is set to JEDEC standard delay DDR4-3200 timing of 22-22-22 at 1.2V. This 260-pin DIMM has gold contact fingers. This RAM has both nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals. Its low-power auto self-refresh (LPASR). Data bus inversion (DBI) is used for data bus On-die VREFDQ generation and calibration. The Kingston Value RAM 16GB DDR4 3200MHz Laptop RAM comes with a lifetime warranty.
