The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically. The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.
Form Factor
226 x 173 mm Micro-ATX Form Factor
Audio
Chip integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 spec
Expansion Slots
PCI
1 x PCIe 2.0 x16 slot 1 x PCIe x1 slot
Memory
Type
Dual-Channel mode
Slots
2 Slots
Supported Memory
1066/1333/1600 MHz
Maximum Memory
up to 16GB Max
Connector & Ports
HDMI
1 x HDMI port
USB (s)
4 x USB 2.0 ports 2 x USB 3.0 ports
LAN Port (s)
Supports Gb LAN 10/100/1000 by Realtek RTL8111G
Supported Storage
SATAIII controller integrated in Intel H81 chipset - Up to 6Gb/s transfer speed. - Supports two SATAIII ports (SATA1~2) by H81
SATAII controller integrated in Intel H81 chipset - Up to 3Gb/s transfer speed. - Supports two SATAII ports (SATA3~4) by H81
Audio
Chip integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 spec
Internal I/O Ports
1 x ATX 24-Pin power connector 1 x 4-pin ATX 12V power connector CPU x 1 / System x 2 FAN connectors 1 x Clear CMOS jumper 2 x SATAIII connectors 2 x SATAII connectors 2 x USB 2.0 connectors 1 x Serial port connector 1 x Front Panel Audio connector 1 x Chassis Intrusion connector
