Gigabyte GA-H81M-DS2 Micro ATX Motherboard

http://www.daffodil-bd.com/web/image/product.template/5219/image_1920?unique=b95710b
(0 review)

Key Features
Model: GA-H81M-DS2
CPU: 4th Generation Intel Processors
Chipset: Intel H81 Express
2 x 1.5V DDR3
3 x PCI Express slot


8,100.00 ৳ 8100.0 BDT 8,100.00 ৳ VAT Excluded 8,800.00 ৳

8,100.00 ৳ VAT Excluded 8,800.00 ৳

Not Available For Sale

    This combination does not exist.


    Share :

    Specification

    Basic Information
    Supported CPUSupport for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1150 package
    L3 cache varies with the CPU
    ChipsetIntel® H81 Express
    BIOS2 x 64 Mbit flash
    Use of licensed AMI EFI BIOS
    Support for DualBIOS™
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    Form FactorMicro ATX Form Factor; 22.6cm x 17cm
    Expansion Slots
    PCI1 x PCI Express x16 slot, running at x16
    2 x PCI Express x1 slots
    (The PCI Express slots conform to PCI Express 2.0 standard.)
    Memory
    TypeDual-channel DDR3 memory architecture
    Slots2 x 1.5V DIMM
    Supported MemorySupport for DDR3 1600/1333 MHz memory modules
    Support for non-ECC memory modules
    Support for Extreme Memory Profile (XMP) memory modules
    Maximum Memory16 GB
    Graphics
    Graphics1 x D-Sub port, supporting a maximum resolution of 1920x1200
    Max Shared Memory1 GB
    Connector & Ports
    D-Sub (s)1 x D-Sub
    USB (s)Chipset:
    Up to 2 USB 3.0/2.0 ports on the back panel
    Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
    LAN Port (s)Realtek® GbE LAN chip (10/100/1000 Mbit)
    Supported StorageChipset:
    2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s devices
    2 x SATA 3Gb/s connectors (SATA2 2/3) supporting up to 2 SATA 3Gb/s devices
    AudioRealtek® ALC887 codec
    High Definition Audio
    2/4/5.1/7.1-channel
    * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
    Internal I/O Ports1 x 24-pin ATX main power connector
    1 x 4-pin ATX 12V power connector
    2 x SATA 6Gb/s connectors
    2 x SATA 3Gb/s connectors
    1 x CPU fan header
    1 x system fan header
    1 x front panel header
    1 x front panel audio header
    2 x USB 2.0/1.1 headers
    1 x Clear CMOS jumper
    TPM (Trusted Platform Module )N/A
    Warranty Information
    Manufacturing Warranty03 Years

    Description

    Gigabyte GA-H81M-DS2 Micro ATX ultra durable motherboard hascompatibility with 4th gen Intel processors. This board also supports dual channel DDR3 maximum 16GB memory and dual Ultra-Fast SATA interface. Focusing on the graphics, it has integrated Intel HD graphics with 1GB shared graphics memory containing a resolution of 1920x1200 Hz for the D-Sub port. This basic motherboard has the facility of GIGABYTE On/Off Chargeâ„¢ for USB devices, LAN with high ESD Protection, and USB 3.0 ports with GIGABYTE 3x USB power. This solid capacitors design board also contains GIGABYTE UEFI DualBIOS Technology and LPT, COM, D-SUB port on the rear panel.
