Gigabyte H410M H Micro ATX Motherboard

http://www.daffodil-bd.com/web/image/product.template/5236/image_1920?unique=e885889
(0 review)

Key Features
Brand: Gigabyte
Model: Gigabyte H410M H
Intel Socket LGA1200 for 10th Gen Processors
8-Channel HD Audio
Smart Fan 5 features
Anti-Sulfur Resistors Design



9,000.00 ৳ 9000.0 BDT 9,000.00 ৳ VAT Excluded

9,000.00 ৳ VAT Excluded

Not Available For Sale

    This combination does not exist.


    Share :

    Specification

    Supported CPU
    1. Support For 10th Generation Intel® Core™ I9 Processors/Intel® Core™ I7 Processors/Intel® Core™ I5 Processors/Intel® Core™ I3 Processors/Intel® Pentium® Processors/Intel® Celeron® Processors In The LGA1200 Package
    2. L3 Cache Varies With CPU
    ChipsetIntel® H410 Express Chipset
    Supported MemoryIntel® Core™ I9/I7 Processors: Support For DDR4 2933/2666/2400/2133 MHz Memory Modules Intel® Core™ I5/I3/Pentium®/Celeron® Processors: Support For DDR4 2666/2400/2133 MHz Memory Modules 2 X DDR4 DIMM Sockets Supporting Up To 64 GB (32 GB Single DIMM Capacity) Of System Memory Dual Channel Memory Architecture Support For ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules (Operate In Non-ECC Mode) Support For Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules Support For Extreme Memory Profile (XMP) Memory Modules
    BIOS1 X 128 Mbit Flash Use Of Licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    RAM TypeDDR4
    FromFactorMicro ATX Form Factor; 22.6cm X 17.4cm
    Internal I/O Ports1 X 24-Pin ATX Main Power Connector 1 X 8-Pin ATX 12V Power Connector 1 X CPU Fan Header 1 X System Fan Header 1 X RGB LED Strip Header 4 X SATA 6Gb/S Connectors 1 X M.2 Socket 3 Connector 1 X Front Panel Header 1 X Front Panel Audio Header 1 X USB 3.2 Gen 1 Header 1 X USB 2.0/1.1 Header 1 X Trusted Platform Module Header (For The GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 Module Only) 1 X Serial Port Header 1 X Clear CMOS Jumper
    AudioRealtek® ALC887 Codec High Definition Audio 2/4/5.1/7.1-Channel
    Expansion Slots
    • 1 X PCI Express X16 Slot, Running At X16
    • 2 X PCI Express X1 Slots



    Operating SystemSupport For Windows 10 64-Bit
    HDMI1 X HDMI Ports, Supporting A Maximum Resolution Of 4096x2160@30 Hz
    LANRealtek® GbE LAN Chip (1000 Mbit/100 Mbit)
    GraphicsIntegrated Graphics Processor-Intel® HD Graphics Support:
    1. 1 X D-Sub Port, Supporting A Maximum Resolution Of 1920x1200@60 Hz
    2. 1 X HDMI Ports, Supporting A Maximum Resolution Of 4096x2160@30 Hz
      * Support For HDMI 1.4 Version And HDCP 2.3.
    Maximum Shared Memory Of 512 MB
    USB4 X USB 3.2 Gen 1 Ports (2 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header) 6 X USB 2.0/1.1 Ports (4 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header)
    BrandGigabyte



    Gigabyte H410M H Micro ATX Motherboard

    Buy your required products Gigabyte H410M H Micro ATX Motherboard Price in Bangladesh. Gigabyte Motherboard Best Price from our online and also you will get free home delivery or pickup from our showroom.

    Gigabyte H410M H 10th Gen Micro ATX Motherboard. Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. Gigabyte H410M can provide users the most comprehensive features and the fastest and smoothest Internet experience. GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. With Smart Fan, 5 users can ensure that their gaming PC can maintain Gigabyte H410M performances while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan, but 5 more hybrid fan headers that support both PWM and Voltage mode fans have also been introduced to make the motherboard more liquid cooling friendly. Achieve fan silence. With Fan Stop, map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, and at what temperature—all of it can be customized to your liking. Gigabyte H410M motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects for gamers. Gigabyte H410M motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change and causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning. GIGABYTE motherboards also feature special anti-surge IC that protect your motherboard, helping to ensure that your PC is equipped to deal with any potentially irregular electrical spikes. There is nothing more harmful to the longevity of your PC than moisture, and most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid and damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fiber weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuits and system malfunction caused by humid and damp conditions. GIGABYTE motherboards use Low RDS(on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users and the environment without impacting system performance. The BIOS is essential for users during the initial setup to allow for the most optimal settings. With a new GUI and easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.
