Model: Gigabyte B460M DS3H AC
Intel Socket LGA1200 for 10th Gen Processors
Chipset: Intel B460 Express
4 x DIMM, Max. 128GB DDR4
Intel Dual Band 802.11ac WIFI
|Chipset||Intel® B460 Express Chipset|
|Supported Memory||Intel® Core™ I9/I7 Processors: Support For DDR4 2933/2666/2400/2133 MHz Intel® Core™ I5/I3/Pentium®/Celeron® Processors: Support For DDR4 2666/2400/2133 MHz 4 X DDR4 DIMM Sockets Supporting Up To 128 GB (32 GB Single DIMM Capacity) Of System Memory Dual Channel Memory Architecture Support For ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules (Operate In Non-ECC Mode) Support For Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules Support For Extreme Memory Profile (XMP) Memory Modules|
|BIOS||2 X 128 Mbit Flash Use Of Licensed AMI UEFI BIOS Support For DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0|
|FromFactor||Micro ATX Form Factor; 24.4cm X 22.5cm|
|Internal I/O Ports||1 X 24-Pin ATX Main Power Connector 1 X 8-Pin ATX 12V Power Connector 1 X CPU Fan Header 2 X System Fan Headers 2 X RGB LED Strip Headers 6 X SATA 6Gb/S Connectors 1 X M.2 Socket 3 Connector 1 X Front Panel Header 1 X Front Panel Audio Header 1 X USB 3.2 Gen 1 Header 2 X USB 2.0/1.1 Headers 1 X Trusted Platform Module Header (For The GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 Module Only) 2 X Serial Port Headers 1 X Clear CMOS Jumper|
|Audio||Realtek® ALC887 Codec High Definition Audio 2/4/5.1/7.1-Channel|
|Operating System||Support For Windows 10 64-Bit|
|LAN||Realtek® GbE LAN Chip (1000 Mbit/100 Mbit)|
|Graphics|| Integrated Graphics Processor-Intel® HD Graphics Support:|
|USB||Chipset: 6 X USB 3.2 Gen 1 Ports (4 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header) 2 X USB 2.0/1.1 Ports On The Back Panel Chipset+USB 2.0 Hub: 4 X USB 2.0/1.1 Ports Available Through The Internal USB Headers|
Buy your required products Gigabyte B460M DS3H Micro ATX Motherboard Price in Bangladesh. Gigabyte Motherboard Best Price from our online and also you will get free home delivery or pickup from our showroom.
Gigabyte B460M DS3H AC 10th Gen WiFi Micro ATX Motherboard. GIGABYTE motherboards use Low RDS(on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy saving which is beneficial for both end-users and the environment without impacting system performance. The onboard 802.11ac WIFI module from Intel supports Dual Band and up to 433 Mbps, 3x faster WIFI speed than 802.11n, and also support BLUETOOTH 4.2. Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features and the fastest and smoothest Internet experience. GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. GIGABYTE Ultra Durable motherboards feature GIGABYTE DualBIOS, an exclusive technology from GIGABYTE that protects arguably one of your PC's most crucial components, the BIOS. GIGABYTE DualBIOS™ means that your motherboard has both a 'Main BIOS' and a 'Backup BIOS', protecting users from BIOS failure due to virus, hardware malfunction, improper OC settings or power failure during the update process. Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change and causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning. With Smart Fan, 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan, but 5 more hybrid fan headers that support both PWM and Voltage mode fans have also been introduced to make the motherboard more liquid cooling friendly. GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects for gamers. GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level.
