ASUS PRIME B760M-K MOTHERBOARD VGA, HDMI, 3x AUDIO JACKS, USB, AURA SYNC,RGB HEADER

http://www.daffodil-bd.com/web/image/product.template/13978/image_1920?unique=94878c7
(0 review)

Key Features
Supported CPU: 14th 13th Gen & 12th Gen Processors
Supported Memory: 2 x DDR5, Max. 96GB 8000(OC)
Graphics Output: 1 x VGA port, 1 x HDMI
Features: 1 x Realtek 2.5Gb Ethernet

19,610.00 ৳ 19610.0 BDT 19,610.00 ৳ VAT Excluded

19,610.00 ৳ VAT Excluded

Not Available For Sale

    This combination does not exist.


    Share :

    Specification

    Basic Information
    Supported CPUIntel Socket LGA1700 For 13th Gen Intel Core & 12th Gen Intel Core,
    Pentium Gold And Celeron Processors
    Supports Intel Turbo Boost Technology 2.0 And Intel Turbo Boost Max Technology 3.0
    ChipsetIntel B760 Chipset
    BIOS128 Mb Flash ROM, UEFI AMI BIOS
    AudioRealtek 7.1 Surround Sound High Definition Audio CODEC
    - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking
    - Supports Up To 24-Bit/192 KHz Playback
    Audio Features
    - Audio Shielding
    - Premium Audio Capacitors
    - Dedicated Audio PCB Layers
    Form FactorMATX Form Factor
    9.6 Inch X 8.3 Inch (24.4cm X 21.1cm)
    Expansion Slots
    PCIIntel® 13th & 12th Gen Processors
    1 X PCIe 4.0 X16 Slot
    Intel® B760 Chipset
    2 X PCIe 4.0 X1 Slots
    Memory
    TypeDDR5
    Slots2 X DIMM Slots
    Supported Memory8000(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)
    /6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-Buffered Memory
    Dual Channel Memory Architecture
    Supports Intel Extreme Memory Profile (XMP)
    Maximum Memory96GB
    Graphics
    Graphics1 X VGA Port
    1 X HDMITM Port
    Software
    Operating SystemWindows® 11, Windows® 10 64-Bit
    Connector & Ports
    USB (S)Rear USB (Total 6 Ports)
    4 X USB 3.2 Gen 1 (5G) Ports (4 X Type-A)
    2 X USB 2.0 Ports (2 X Type-A)
    Front USB (Total 5 Ports)
    1 X USB 3.2 Gen 1 (5G) Header Supports 2 Additional USB 3.2 Gen 1 Ports
    2 X USB 2.0 Headers Support 3 Additional USB 2.0 Ports
    Supported StorageTotal Supports 2 X M.2 Slots And 4 X SATA 6Gb/S Ports
    Intel 13th & 12th Gen Processors
    M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode)
    Intel B760 Chipset
    M.2_2 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode)
    4 X SATA 6Gb/S Ports
    Internal I/O PortsFan And Cooling Related
    1 X 4-Pin CPU Fan Header
    2 X 4-Pin Chassis Fan Headers
    Power Related
    1 X 24-Pin Main Power Connector
    1 X 8-Pin +12V Power Connector
    Storage Related
    2 X M.2 Slots (Key M)
    4 X SATA 6Gb/S Ports
    USB
    1 X USB 3.2 Gen 1 (5G) Header Supports 2 Additional USB 3.2 Gen 1 Ports
    2 X USB 2.0 Headers Support 3 Additional USB 2.0 Ports
    Miscellaneous
    2 X Addressable Gen 2 Headers
    1 X Aura RGB Header
    1 X Clear CMOS Header
    1 X COM Port Header
    1 X Front Panel Audio Header (AAFP)
    1 X S/PDIF Out Header
    1 X Speaker Header
    1 X SPI TPM Header (14-1pin)
    1 X 10-1 Pin System Panel Header
    TPM (Trusted Platform Module )1 X SPI TPM Header (14-1pin)
    Others
    Special FeaturesASUS 5X PROTECTION III
    - DIGI+ VRM
    - LANGuard
    - Overvoltage Protection
    - SafeSlot Core
    - Stainless-Steel Back I/O
    ASUS Q-Design
    - Q-DIMM
    - Q-LED Core
    - Q-Slot
    ASUS EZ DIY
    - ProCool
    ASUS Thermal Solution
    - VRM Heatsink Design
    Aura Sync
    - Aura RGB Header
    - Addressable Gen 2 Headers
    Bundled SoftwareASUS Exclusive Software
    Armoury Crate
    - Aura Sync
    - Fan Xpert 2+
    - Power Saving
    - Two-Way AI Noise Cancellation
    AI Suite 3
    - DIGI+ VRM
    - PC Cleaner
    ASUS CPU-Z
    Norton 360 Deluxe (60 Days Free Trial)
    WinRAR
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode
    Warranty Information
    Warranty3 Years

    Asus PRIME B760M-K DDR5 mATX Motherboard

    The Asus PRIME B760M-K DDR5 mATX Motherboard is a feature-rich and highly capable motherboard designed to support the latest Intel processors, providing a solid foundation for building a high-performance desktop system. It's engineered to accommodate 13th Gen Intel Core, 12th Gen Intel Core, Pentium Gold, and Celeron processors, offering excellent compatibility for various computing needs. The motherboard is built around the Intel B760 chipset and boasts a multitude of features and capabilities that make it a compelling choice for both enthusiasts and mainstream users. It comes with a 128 Mb Flash ROM UEFI AMI BIOS, ensuring smooth and user-friendly system setup and configuration. One notable highlight of the PRIME B760M-K is its support for DDR5 memory, with two DIMM slots that can accommodate a maximum of 96GB of RAM. This memory type offers impressive speeds, with overclocking support up to 8000 MHz, providing ample bandwidth for demanding tasks. The motherboard also caters to gamers and multimedia enthusiasts with a robust graphics configuration. It includes a VGA port and an HDMI port, offering versatile display options. The Realtek 7.1 Surround Sound High Definition Audio CODEC, complete with audio shielding, premium audio capacitors, and dedicated audio PCB layers, delivers exceptional audio quality for an immersive entertainment experience. In terms of connectivity, the PRIME B760M-K is well-equipped. It features various USB ports, both on the rear and front panels, along with multiple M.2 slots and SATA 6Gb/s ports for storage options. This ensures ample connectivity and storage expansion capabilities. ASUS has integrated several premium features into the motherboard, such as ASUS 5X PROTECTION III for enhanced durability and ASUS EZ DIY features for convenient installation and maintenance. Additionally, Aura Sync technology allows for customizable RGB lighting, while bundled software like Armoury Crate, AI Suite 3, and ASUS CPU-Z provides tools for system optimization and customization.
